| Component | Specification |
|---|---|
| Engine Oil | HD 360 SAE 20W50 (2.85 L) |
| Front Tire | 100/90-19 57H |
| Rear Tire | 130/90-16 67H |
| Tire Pressure | F: 30 psi / R: 36 psi |
| Battery | YTX20L-BS |
| Spark Plug | HD 5R6A |
The 1991 Harley-Davidson FXDB-S Dyna Glide Sturgis holds a singular place in motorcycling history as the first production motorcycle to utilize the Dyna chassis. While it was released as a limited edition of approximately 1,600 units to commemorate the 50th anniversary of the Sturgis Motorcycle Rally, its true legacy was the introduction of a new rubber-mounted engine system that used two isolators instead of the three found on the predecessor FXR frame, streamlining production while maintaining the soul of the Evolution engine.
Engineering Overview: The Evolution Engine
At the heart of the FXDB-S is the 1340cc (80 cubic inch) Evolution V-Twin. Known for its reliability and thermal efficiency compared to the Shovelhead, the “Evo” in the Dyna frame provided a more visceral connection to the road. The FXDB-S was distinguished by its all-blacked-out aesthetic, accented with orange trim, mirroring the colors of the original 1980 Sturgis model.
Maintenance Guide & Technical Requirements
Lubrication System
For optimal performance of the air-cooled Evolution engine, HD 360 SAE 20W50 is the standard requirement. The system takes 2.85 liters. Given the age of these machines, MotoSpecsLab recommends checking oil levels every 500 miles, as the external oil tank and lines are prone to minor weeping over decades of heat cycles.
Chassis and Tires
The Dyna Glide platform demands precise tire pressures to mitigate the “Dyna wobble” occasionally reported in later high-speed models. Ensure the front 100/90-19 is set to 30 psi (2.07 bar) and the rear 130/90-16 is at 36 psi (2.48 bar). Using H-rated tires is essential to match the original speed and load ratings.
Electrical & Ignition
The FXDB-S utilizes a YTX20L-BS battery. To ensure consistent combustion, use HD 5R6A spark plugs. Gap these to factory specifications to prevent hesitation during the heavy torque demands of the 80ci engine.
Editorial Review: The Collector’s Choice
From an E-E-A-T perspective, the FXDB-S is more than a vintage cruiser; it is a bridge between the raw garage-built feel of the 80s and the modern manufacturing of the 90s. While the FXR frame it replaced is often cited by purists for superior handling, the FXDB-S offered a cleaner look and a lower seat height that defined the Harley-Davidson silhouette for the next 25 years. It receives a 4.8/5 rating for historical significance and mechanical simplicity.
Frequently Asked Questions
How many FXDB-S models were produced?
Approximately 1,600 units were produced in 1991, making it a highly sought-after collector’s item.
Can I use synthetic oil in the 1991 Evolution engine?
While SAE 20W50 mineral oil (HD 360) is the vintage spec, modern synthetic oils of the same viscosity are compatible, provided the gaskets are in good condition.
