| Component | Specification |
|---|---|
| Engine Type | 249cc Liquid-Cooled 4-Stroke Single |
| Engine Oil | SAE 10W-40 (API SG-SM / JASO MA/MA2) |
| Oil Capacity | 0.8 Liters |
| Spark Plug | NGK CPR8EB-9 |
| Tire Size (Front) | 80/100-21 51M |
| Tire Size (Rear) | 100/90-19 57M |
| Tire Pressure | 1.0 bar (15 psi) Front/Rear |
The 2015 Kawasaki KX 250 (KX252FFA) represents a pinnacle of motocross engineering, most notably for being the first in its class to successfully integrate a Dual-Injector Fuel Injection system. This setup utilizes a downstream injector for smooth, instant response and an upstream injector located near the airbox to maximize high-RPM power delivery—a design philosophy directly inherited from Kawasaki’s factory racing program.
Engineering Analysis: The KX252FFA Architecture
Under the MotoSpecsLab lens, the KX252FFA stands out due to its refined Showa Separate Function Fork (SFF) Type 2. By isolating the damping duties to the left leg and the spring to the right, Kawasaki reduced friction and weight while simplifying the tuning process for professional riders. The engine features a Bridge-Box bottom piston, which remains a benchmark for durability in high-revving 250cc powerplants.
Maintenance Essentials
Lubrication System
The KX252FFA requires precise lubrication to maintain its high-compression performance. We recommend a high-zinc SAE 10W-40 oil meeting JASO MA2 standards. With a capacity of only 0.8 liters, the oil undergoes significant thermal stress; therefore, MotoSpecsLab advises changing the fluid every 6-10 hours of competitive use.
Ignition and Electrical
Unlike modern electric-start models, the 2015 KX 250 does not carry a traditional lead-acid battery. Instead, it relies on a large-capacity ECU Capacitor to provide the initial surge required to power the fuel pump and ECU during the kick-start stroke. For optimal combustion, ensure the NGK CPR8EB-9 spark plug is gapped correctly and replaced if any fouling is detected.
Chassis and Handling
Handling is dictated by the interaction between the aluminum perimeter frame and the tire contact patch. The factory-specified 80/100-21 (Front) and 100/90-19 (Rear) tires provide the necessary bite for aggressive cornering. Maintaining a consistent 1.0 bar (15 psi) is critical for preventing rim strikes while ensuring the tire carcass can flex sufficiently to provide traction on intermediate terrain.
Editor’s Verdict
The KX252FFA is a precision tool for the serious racer. While it demands a rigorous maintenance schedule—particularly regarding oil quality and valve clearances—its dual-injection powerband offers a competitive edge that remains relevant in the used market today. It is a testament to Kawasaki’s ‘Green Team’ engineering excellence.
Frequently Asked Questions
Q: What is the recommended spark plug gap for the KX252FFA?
A: The NGK CPR8EB-9 should typically be gapped between 0.8mm and 0.9mm.
Q: Can I use automotive oil in my KX 250?
A: No. Automotive oils often contain friction modifiers that will cause the motorcycle’s wet clutch to slip. Always use JASO MA/MA2 certified oils.
