| Parameter | Specification |
|---|---|
| Production Years | 08/2016 – 2017 |
| Engine Oil | SAE 5W-40, API SL / JASO MA2 (2.9 L) |
| Battery Type | YTX14-BS |
| Spark Plug | NGK DCPR8E (0.8–0.9 mm gap) |
| Front Tire | 110/80 R19 59V |
| Rear Tire | 140/80 R17 69V |
Historical Engineering Highlight: The 2016-2017 ‘0B06’ iteration of the BMW F 700 GS marked a critical evolution in the F-series lineage. To meet stringent Euro 4 emissions standards, BMW Motorrad didn’t just tweak the exhaust; they introduced a full Ride-by-Wire (E-gas) throttle system. This allowed for the integration of selectable riding modes (‘Rain’ and ‘Road’ as standard), making the F 700 GS one of the first middleweight adventure-tourers to offer such sophisticated electronic engine management as a standard feature.
Technical Engine Analysis
The 798cc Rotax-derived parallel twin remains a masterclass in balance, utilizing a unique third connecting rod as a counterbalance to minimize vibrations. In this Euro 4 configuration, the engine provides a linear power delivery that favors usability over raw peak numbers. Maintenance on this unit is straightforward, but precision is key—specifically regarding the 2.9-liter oil capacity and the use of high-quality JASO MA2 synthetic fluids to protect the wet clutch system.
Maintenance Guide: Key Components
Ignition System
The 0B06 model utilizes NGK DCPR8E spark plugs. For optimal combustion efficiency and to maintain Euro 4 emission compliance, the electrode gap must be strictly set between 0.8 and 0.9 mm. Fouled plugs in these models can often lead to ‘stumbling’ at low RPMs, a known quirk of the lean-running Euro 4 maps.
Electrical & Battery
The electrical system is supported by a YTX14-BS battery. Given the increased electronic load from the Ride-by-Wire system and optional ESA (Electronic Suspension Adjustment), maintaining a healthy charge is vital. If the bike is stored for more than two weeks, a CAN-bus compatible charger is highly recommended to prevent parasitic drain from the ECU.
Chassis & Tire Pressure Management
The F 700 GS is designed for versatility, which is reflected in its tire pressure requirements. Proper inflation is critical for the 19-inch front wheel’s tracking stability.
- Solo Riding: Front: 2.2 bar (31.9 psi) / Rear: 2.5 bar (36.3 psi)
- Fully Loaded / Pillion: Front: 2.5 bar (36.3 psi) / Rear: 2.9 bar (42.1 psi)
MotoSpecsLab Verdict
The BMW F 700 GS (0B06) represents the pinnacle of the 700-series development. By combining the accessibility of a lower seat height with the modern electronics of the Euro 4 era, it remains a highly sought-after machine on the used market for riders seeking BMW’s legendary build quality without the intimidating height of the R 1200 GS.
