| Specification | Value / Requirement |
|---|---|
| Model Designation | 0382 (K25 Adventure Variant) |
| Production Years | 2006 – 2013 |
| Oil Capacity | 4.0 Liters (with filter) |
| Tire Size (Front) | 110/80 R 19 59V |
| Tire Size (Rear) | 150/70 R 17 69V |
| Battery Type | YTX14-BS |
The BMW R 1200 GS Adventure (0382) represents a pivotal era in adventure motorcycling, bridging the gap between mechanical purity and the dawn of advanced electronics. A unique engineering highlight of this specific generation is the implementation of the EVO braking system and the 2010 introduction of the DOHC (Double Overhead Camshaft) engine derived from the HP2 Sport, which significantly increased the rev ceiling and torque spread compared to the earlier single-cam variants.
Engineering Overview
Known internally as the 0382, this Adventure variant features a massive 33-liter fuel tank and increased suspension travel (210mm front / 220mm rear) over the standard GS. The transition in 2010 from the 1170cc SOHC engine to the DOHC configuration marked the pinnacle of the air/oil-cooled Boxer evolution, delivering 110 hp and a more robust exhaust note via the electronically controlled exhaust flap.
Maintenance Specifications
1. Lubrication System
Oil requirements vary significantly based on the production year. For 2006-2009 models, BMW recommended mineral or semi-synthetic SAE 15W-50 or 20W-50. With the introduction of the DOHC engine in 2010-2013, the specification shifted to a SAE 5W-40 Full Synthetic oil to accommodate tighter tolerances and higher operating temperatures. The system capacity remains constant at 4.0 liters.
2. Wheels and Tires
The 0382 utilizes cross-spoke wheels designed for tubeless operation. Maintaining correct pressure is critical for handling stability and tire longevity:
- Solo Riding: Front 2.2 bar (31.9 psi) / Rear 2.5 bar (36.3 psi)
- Maximum Load/Pillion: Front 2.5 bar (36.3 psi) / Rear 2.9 bar (42.1 psi)
3. Ignition & Electrical
The ignition system requires specific spark plugs to ensure efficient combustion and prevent knocking. Models from 2006-2009 utilize the NGK DCPR8EKC (dual electrode), while the 2010-2013 DOHC models require the NGK MAR8B-JDS. The electrical system is supported by a YTX14-BS battery, which must be kept at a high state of charge to prevent CAN-bus errors during startup.
Professional Review: The MotoSpecsLab Verdict
The BMW R 1200 GS Adventure (0382) is often cited by purists as the most reliable long-distance platform ever built by BMW Motorrad. While later liquid-cooled models offer more power, the 2006-2013 generation provides a tactile mechanical connection that is increasingly rare. For the home mechanic, the 0382 is relatively accessible, though the DOHC valve adjustments (using shims rather than screw-and-locknut) require more precision during the 12,000-mile service intervals. It remains a gold standard for global exploration.
