| Component | Specification |
|---|---|
| Model | Honda CBR 600 F (VERGASER) – PC35 |
| Production Years | 1999-2000 |
| Engine Oil | 10W-40 JASO MA (3.3 L) |
| Tire Dimensions | F: 120/70 ZR 17 / R: 180/55 ZR 17 |
| Tire Pressure | F: 2.5 bar (36 psi) / R: 2.9 bar (42 psi) |
| Battery Type | YTX9-BS |
| Spark Plug | NGK CR9EH-9 |
The 1999 introduction of the Honda CBR 600 F PC35 marked a historic engineering milestone: it was the first CBR600 to utilize an aluminum twin-spar frame, replacing the previous steel frame of the PC31. This change reduced the chassis weight by approximately 7kg while significantly increasing torsional rigidity. Crucially, the 1999-2000 model year represents the final evolution of the 600F series to utilize Keihin 34mm carburetors (Vergaser), offering a linear throttle response that many purists still prefer over the subsequent fuel-injected F4i models.
Technical Engineering Overview
The PC35 engine is a liquid-cooled 599cc inline-four, delivering approximately 106 hp. Unlike its predecessors, the PC35 featured a shorter stroke and larger bore, allowing for a higher redline and a more aggressive power delivery. The inclusion of a ram-air system integrated into the front fairing significantly improved high-speed performance by increasing airbox pressure.
Maintenance Guide
Lubrication System
For optimal engine longevity and clutch performance, use a high-quality 10W-40 JASO MA synthetic or semi-synthetic oil. The total capacity for an oil and filter change is 3.3 liters. Ensure the motorcycle is level when checking the sight glass.
Ignition & Electrical
The PC35 uses NGK CR9EH-9 spark plugs. Given the tight packaging of the aluminum frame, accessing the plugs requires removing the fuel tank and airbox. The electrical system is powered by a YTX9-BS battery; ensure the charging system (regulator/rectifier) is inspected regularly, as this was a known weak point in Hondas of this era.
Chassis & Tires
The PC35 handles best with its factory-specified pressures of 2.5 bar (front) and 2.9 bar (rear). The 180/55 ZR 17 rear tire provides a substantial contact patch, but maintaining correct pressure is vital to prevent ‘cupping’ and ensure neutral turn-in characteristics.
Expert Verdict
The CBR 600 F PC35 remains one of the most versatile motorcycles ever built. It bridges the gap between the comfortable sport-tourers of the early 90s and the track-focused supersports of the 2000s. Its build quality is exemplary, and with proper maintenance of the carburetors and cam chain tensioner, these machines easily exceed 100,000 kilometers.
