| Specification | Data |
|---|---|
| Production Years | 2015 – 2020 |
| Engine Oil | SAE 10W-30 API SG+ / JASO MB (1.4 L) |
| Tire Size (Front/Rear) | 110/70-16 M/C 52S / 130/70-16 M/C 61S |
| Tire Pressure (F/R) | 2.0 bar / 2.25-2.5 bar |
| Battery Type | YTZ12S (VRLA) |
| Spark Plug | NGK LMAR8A-9 |
The Honda SH 300i NF05 generation represents a pivotal moment in urban mobility engineering. Notably, it was the first high-performance scooter in its class to achieve full Euro 4 compliance while simultaneously reducing fuel consumption and increasing low-to-mid range torque through a revised PGM-FI mapping and a redesigned steel cradle frame. This iteration also introduced the ‘Smart Key’ system to the SH flagship, cementing its status as the premium benchmark for large-wheel scooters.
Engineering Overview
At the heart of the NF05 is a 279cc liquid-cooled, single-cylinder four-valve engine. Unlike many competitors that utilize JASO MA oils (designed for wet clutches), the SH 300i utilizes a JASO MB specification. This is a critical technical distinction; JASO MB oils are lower-friction lubricants designed for scooters with dry centrifugal clutches, contributing to the NF05’s superior fuel efficiency and reduced internal parasitic drag.
The chassis features 16-inch wheels, which provide motorcycle-like stability at high speeds, a characteristic that distinguishes the SH series from smaller-wheeled urban commuters. The NF05 also saw a significant upgrade in LED lighting technology, providing a high-intensity beam pattern that significantly improves safety during nocturnal urban transit.
Maintenance Protocol
Lubrication System
For optimal engine longevity, the oil must be changed according to the service interval using 1.4 liters of SAE 10W-30. Ensure the oil meets the JASO MB standard. Using JASO MA oil will not damage the engine but may result in slightly higher fuel consumption and reduced efficiency.
Tires and Contact Patch
The NF05 uses a staggered 16-inch setup. Maintaining precise pressure is vital for the linked braking system (ABS) to function correctly. Front pressure should be held at 2.0 bar (29 psi). The rear requires 2.25 bar (33 psi) for solo commuting, but must be increased to 2.5 bar (36 psi) when the top box is loaded or a pillion is present to prevent sidewall deformation.
Electrical and Ignition
The ignition system relies on the NGK LMAR8A-9 spark plug. This long-reach plug is essential for the high-compression combustion chamber of the 279cc mill. The electrical system is powered by a YTZ12S battery; given the Smart Key’s constant parasitic draw for the proximity sensor, maintaining battery health with a trickle charger during long periods of inactivity is highly recommended.
Frequently Asked Questions
Q: Can I use 10W-40 oil instead of 10W-30?
A: While 10W-40 is acceptable in extremely hot climates, Honda recommends 10W-30 JASO MB for the best balance of protection and fuel economy in the NF05 engine.
Q: How often should the spark plug be replaced?
A: Under standard conditions, the NGK LMAR8A-9 should be inspected every 12,000 km and replaced as necessary, though many technicians recommend replacement at this interval to maintain peak fuel atomization.
