| Component | Specification |
|---|---|
| Engine Type | Parallel Twin, 270° Crankshaft (Euro 5+) |
| Engine Oil | SAE 10W-40 JASO T 903: MA2 (3.0 L) |
| Front Tire | 110/80R19M/C 59V |
| Rear Tire | 150/70R17M/C 69V |
| Tire Pressure (F/R) | 2.3 bar (33 psi) / 2.5 bar (36 psi) |
| Battery Type | FTZ10S |
| Spark Plug | NGK LMAR8BI-9 |
The Suzuki DL 800 V-Strom (DL800/24) represents a pivotal shift in Suzuki’s engineering philosophy. While the ‘V-Strom’ nameplate historically signified a 90-degree V-twin layout, the DL800 introduces a sophisticated 776cc parallel-twin engine. A unique engineering highlight of this powerplant is the Suzuki Cross Balancer system—the first of its kind on a production motorcycle to position two balancers at 90° to the crankshaft, effectively neutralizing vibrations while allowing for a more compact engine footprint compared to the traditional V-twin.
Engineering Evolution & Performance
The Euro 5+ compliant DL800/24 is designed for high-torque delivery at low-to-mid RPMs. By utilizing a 270-degree firing order, Suzuki engineers have successfully mimicked the power pulse and traction characteristics of a V-twin, providing the ‘character’ riders expect from the Strom family. The transition to Euro 5+ standards involves refined ECU mapping and exhaust catalysis to ensure minimal emissions without sacrificing the 82hp peak output.
Maintenance Guide
Lubrication System
For the DL800/24, engine longevity is contingent on using SAE 10W-40 JASO T 903: MA2 certified oil. The system requires exactly 3.0 liters for a standard change with filter. The MA2 specification is critical to prevent clutch slippage in the high-torque parallel-twin environment.
Chassis & Contact Patch
The DL 800 utilizes a 19-inch front and 17-inch rear configuration, striking a balance between road stability and light off-road capability. Maintaining the factory-specified 2.3 bar (Front) and 2.5 bar (Rear) is vital for the Suzuki Intelligent Ride System (S.I.R.S) to function correctly, particularly the Traction Control parameters.
Electrical & Ignition
The ignition system relies on high-performance NGK LMAR8BI-9 laser iridium spark plugs. These are essential for the lean-burn cycles required by Euro 5+ regulations. For electrical reliability, the FTZ10S battery provides the high cold-cranking amps (CCA) necessary to turn over the high-compression twin-cylinder engine.
Frequently Asked Questions
Q: How often should the NGK LMAR8BI-9 plugs be inspected?
A: Under standard operating conditions, inspection is recommended every 12,000 km, though iridium plugs typically offer extended service life.
Q: Can I use synthetic 10W-50 oil?
A: Suzuki recommends 10W-40 MA2. While 10W-50 may be used in extreme heat, it may slightly alter fuel efficiency and cold-start lubrication flow.
