| Specification | Data |
|---|---|
| Production Years | 2016 – 2019 |
| Engine Oil | SAE 10W-40 (JASO MA) |
| Oil Capacity (Filter) | 2.6 Liters |
| Tire Size (F/R) | 120/70 ZR 17 / 180/55 ZR 17 |
| Spark Plug | NGK LMAR8A-9 |
| Battery | YTZ10S |
Engineering Highlight: The Tracer 700 RM14/RM15 platform is defined by its 689cc Crossplane 2 (CP2) engine. Unlike traditional parallel twins, Yamaha utilized a 270-degree crankshaft design to provide an uneven firing interval. This engineering choice was specifically designed to provide the rider with a more direct connection between the throttle and the rear tire, mimicking the torque characteristics and character of a V-twin while maintaining the compact dimensions of an inline engine.
Technical Review: The RM14/RM15 Platform
Introduced as the sport-touring sibling to the hyper-naked MT-07, the RM14 (and the restricted RM15) brought a longer swingarm (50mm increase) to enhance stability under touring loads. While the engine remains the heart of the machine, the Euro 4 compliance necessitated precise fueling maps and a sophisticated catalytic converter system. At MotoSpecsLab, we categorize this era as the ‘sweet spot’ of mechanical simplicity and modern emissions control.
Maintenance & Fluid Specifications
Proper lubrication is critical for the CP2’s longevity. The system requires SAE 10W-40 meeting API SG or higher and JASO MA standards. During a standard oil change, 2.3 liters are required, but this increases to 2.6 liters if the filter is replaced. For a completely dry engine (post-rebuild), the capacity is 3.0 liters.
The ignition system relies on NGK LMAR8A-9 spark plugs. It is vital to maintain a gap of 0.8 – 0.9 mm to ensure optimal combustion efficiency and prevent Euro 4 related stumbling at low RPMs.
Chassis, Tires, and Loading
The Tracer 700 utilizes a 17-inch wheel setup, allowing for a wide range of sport-touring rubber. The factory recommended pressures are 2.25 bar (33 psi) for the front and 2.50 bar (36 psi) for the rear. However, for riders carrying a pillion or heavy luggage, the rear pressure should be increased to 2.90 bar (42 psi) to maintain carcass stability and prevent overheating.
FAQ Section
What battery is required for the 2016-2019 Tracer 700?
The motorcycle uses a YTZ10S battery. It is recommended to use an AGM (Absorbed Glass Mat) variant to handle the vibration levels inherent in the twin-cylinder layout.
Can I use synthetic oil?
Yes, provided it meets the JASO MA standard. Synthetic 10W-40 is excellent for the Tracer 700, particularly for riders who engage in long-distance touring or frequent cold starts.
How often should spark plugs be checked?
Under standard operating conditions, spark plugs should be inspected every 10,000 km and replaced every 20,000 km to ensure peak performance.
