| Feature | Specification |
|---|---|
| Production Years | 1984 – 1999 |
| Engine Oil | SAE 10W-40 / 20W-40 (2.0 L) |
| Front Tire | 3.50-18 56S |
| Rear Tire | 4.00-18 64S |
| Tire Pressure (F/R) | 1.8 bar / 2.0 bar |
| Battery Type | YB7-A |
| Spark Plug | NGK BP7ES |
A unique engineering highlight of the Yamaha SR 500 48T is its transition in 1984 to an 18-inch front wheel (down from the 19-inch of the 2J4 model) and the refinement of the ‘sight glass’ on the cylinder head. This window allows the rider to visually confirm the piston’s position at Top Dead Center (TDC), a crucial feature for mastering the legendary ‘kickstart ritual’ necessitated by its lack of an electric starter.
Engineering Overview
The 48T series represents the maturation of the SR 500 platform. Powered by a 499cc air-cooled SOHC single-cylinder engine, the 48T utilized a dry-sump lubrication system where the frame itself acts as the oil reservoir. This design contributes to better cooling and a narrower engine profile. The 48T also saw the introduction of a revamped carburetor setup and improved braking components compared to its predecessors.
Maintenance Protocol
Lubrication System
The SR 500 is sensitive to oil quality. We recommend a high-zinc SAE 10W-40 or 20W-40 (API SE/SF) to protect the flat-tappet valve train. Total capacity is 2.0 Liters. Always check the oil level while the bike is upright and the engine is at operating temperature.
Ignition & Electrical
The 48T relies on a YB7-A battery to stabilize the electrical system, though the CDI ignition functions independently for starting. The NGK BP7ES spark plug should be gapped to 0.7-0.8mm for optimal combustion efficiency.
Chassis & Tires
Handling precision on the 48T is highly dependent on tire pressure. Maintain 1.8 bar (26 psi) in the front 3.50-18 tire and 2.0 bar (29 psi) in the rear 4.00-18 tire. Over-inflation can lead to excessive vibration, a known characteristic of large-capacity singles.
MotoSpecsLab Professional Verdict
The Yamaha SR 500 48T is an icon of mechanical honesty. It rewards the disciplined owner with a tactile riding experience that modern machines cannot replicate. For the technician, it offers an accessible platform where every component serves a clear purpose, making it one of the most maintainable classic motorcycles in existence.
Frequently Asked Questions
How often should I change the oil?
For the 48T, we recommend oil changes every 3,000 km (1,800 miles) or annually, as the air-cooled engine subjects the lubricant to significant thermal stress.
Why does my SR 500 kick back during starting?
Kickback is usually caused by incorrect timing or attempting to start before reaching TDC. Ensure the indicator in the cylinder head sight glass is visible before applying a full, committed stroke.
