| Component | Specification |
|---|---|
| Model / Year | XP560/22 (2022 – Present) |
| Engine Oil | SAE 10W-40 (API SG+, JASO MA2) |
| Oil Capacity | 2.7L (Periodic), 2.9L (Filter), 3.5L (Total) |
| Tires (F/R) | 120/70R15 M/C 56H / 160/60R15 M/C 67H |
| Tire Pressure | F: 33 psi | R: 36 psi (Solo) / 41 psi (Passenger) |
| Spark Plug | NGK LMAR8G (0.7–0.8 mm gap) |
| Battery | YTZ12S |
Engineering Highlight: The Yamaha T-MAX 560 remains the gold standard for the ‘Sport Scooter’ category primarily due to its unique chassis architecture. Unlike traditional scooters where the engine acts as part of the swingarm, the XP560/22 mounts its 562cc parallel-twin engine rigidly within a die-cast aluminum twin-spar frame. This reduces unsprung weight significantly, allowing the rear suspension to react with the precision of a supersport motorcycle.
Maintenance Protocol & Fluid Dynamics
To maintain the EURO 5 compliant engine’s longevity, the lubrication system requires strict adherence to JASO MA2 standards. While the total capacity is 3.5 liters, a standard oil and filter service requires 2.9 liters. Using a 10W-40 viscosity ensures optimal flow through the integrated wet clutch and centrifugal transmission components, even under high thermal loads characteristic of urban stop-and-go traffic.
Ignition and Electrical Systems
The XP560/22 utilizes the NGK LMAR8G long-reach spark plug. It is critical to verify the electrode gap of 0.7–0.8 mm before installation, as the high-compression ratio of the 560cc engine is sensitive to spark timing and intensity. The electrical system is anchored by the YTZ12S battery, providing the high cold-cranking amps (CCA) necessary for the Smart Key system and sophisticated TMAX electronics suite.
Editorial Performance Review
From the perspective of MotoSpecsLab, the 2022+ iteration of the T-MAX 560 represents the pinnacle of maxi-scooter engineering. The transition to EURO 5 was achieved without sacrificing the linear torque delivery the model is known for. Handling is exceptionally neutral; the 15-inch wheel configuration provides a perfect balance between high-speed stability and the flickability required for filtering through traffic.
The braking system, featuring radial-mount 4-pot calipers at the front, offers feedback that rivals middleweight naked bikes. For owners, the primary maintenance focus should be tire pressure monitoring; the rear 160/60R15 tire is sensitive to pressure drops, which can lead to ‘heavy’ steering feel if allowed to fall below the recommended 36 psi.
Frequently Asked Questions (FAQ)
How often should the oil be changed?
While Yamaha provides specific intervals in the manual, for high-performance use, we recommend periodic checks every 5,000 km, with a full oil and filter change every 10,000 km or annually.
Can I use automotive 10W-40 oil?
No. The T-MAX 560 requires JASO MA2 rated oil to ensure the internal clutch mechanisms do not slip. Automotive oils often contain friction modifiers that are incompatible with this engine’s design.
