| Component | Specification |
|---|---|
| Engine Oil | SAE 10W-40 (API SG+, JASO MA) – 1.10 L |
| Front Tire | 120/70-16 M/C 57P (2.1 bar / 30 psi) |
| Rear Tire | 140/70-15 M/C 69P (2.3 – 2.5 bar) |
| Battery | YTZ7S (12V Maintenance Free) |
| Spark Plug | NGK CR9E |
A unique engineering highlight of the Yamaha VP 125 X-CITY (SE43) is its unconventional wheel diameter configuration. Unlike most city scooters that utilize matching 14-inch or 16-inch sets, Yamaha engineers opted for a 16-inch front wheel paired with a 15-inch rear. This specific geometry was designed to provide the high-speed gyroscopic stability of a motorcycle while maintaining a lower center of gravity and sufficient under-seat storage space, a feat rarely achieved in the 125cc class during its 2007–2016 production run.
Engineering Overview
The SE43 chassis houses a liquid-cooled, 4-stroke, single-cylinder SOHC engine. The fuel injection system ensures crisp throttle response across the urban powerband, while the telescopic front forks and twin rear shocks are tuned for European cobblestones. The braking system features large-diameter discs (270mm front, 240mm rear), providing significant stopping power for a vehicle with a wet weight of approximately 160kg.
Maintenance Protocol
As the Editor-in-Chief of MotoSpecsLab, I recommend a strict adherence to the lubrication schedule. The 1.10-liter oil capacity is relatively small for a high-revving 125cc unit; therefore, monitoring oil levels every 1,000km is vital to prevent thermal degradation.
- Lubrication: Use a high-quality synthetic blend 10W-40. Ensure the JASO MA rating is present to protect internal components.
- Ignition: The NGK CR9E plug should be inspected for carbon fouling every 6,000km. A clean spark is essential for the SE43’s fuel injection mapping.
- Tires: Given the unique 16″/15″ setup, maintaining the 2.1 bar front and 2.3 bar rear pressure is critical for steering neutrality.
Technical FAQ
What battery is required for the X-CITY 125?
The model uses a YTZ7S battery. This is a high-performance, factory-activated AGM battery. Using a lower-spec equivalent may result in starting difficulties during cold cycles.
Can I use car oil in my VP 125?
No. The VP 125 requires JASO MA certified oil. Automotive oils often contain friction modifiers that are not compatible with the specific internal tolerances and seals of this scooter’s engine architecture.
