| Feature | Specification |
|---|---|
| Engine | 689cc CP2 Parallel Twin |
| Model Year | 2023-present |
| Engine Oil | Yamalube 10W-40 (2.60 L) |
| Tire Front | 90/90-21 M/C 54V |
| Tire Rear | 150/70R18 M/C 70V |
| Spark Plug | NGK LMAR8AD-9 |
| Battery | YTZ10S |
While the standard Tenere 700 is celebrated for its hardcore off-road lineage dating back to the 1983 XT600Z, the XTZ700EXP (Explore Edition) represents a significant engineering shift toward ergonomic accessibility. This edition features a unique suspension geometry that reduces seat height by 15mm through shorter travel KYB components, specifically tuned to improve high-speed stability and touring comfort without sacrificing the platform’s legendary reliability.
Technical Performance & Engineering Analysis
At the heart of the XTZ700EXP is the crossplane-concept CP2 engine. Known for its linear torque delivery and 270-degree crank, the Explore Edition enhances the touring experience by including a dedicated quickshifter as standard equipment. This allows for seamless upshifts under load, a critical feature when navigating technical mountain passes or accelerating onto highways with fully loaded panniers.
Maintenance Guide: MotoSpecsLab Standards
Lubrication System
For optimal clutch performance and gearbox longevity, MotoSpecsLab recommends Yamalube 10W-40 (JASO MA2). The total oil capacity for a filter change is 2.60 Liters. Adhering to the JASO MA2 standard is non-negotiable to prevent clutch slippage in the high-torque CP2 engine.
Chassis & Tires
The Explore Edition utilizes a specific tire combination designed for a 70/30 street-to-dirt ratio. Maintain the following pressures for optimal carcass heat management and grip:
- Front (90/90-21): 2.25 bar (33 psi)
- Rear (150/70R18): 2.50 bar (36 psi)
Electrical & Ignition
To ensure reliable starting in remote environments, the YTZ10S battery must be maintained with a smart charger during storage. For ignition, the NGK LMAR8AD-9 spark plugs are essential for maintaining the precise combustion timing required by Yamaha’s ECU mapping.
Editorial Review: MotoSpecsLab Verdict
The XTZ700EXP is the most logical evolution of the Tenere line for the real-world rider. By lowering the center of gravity and refining the suspension for road-biased adventure touring, Yamaha has addressed the only major criticism of the original T7: its intimidating height. From a technical standpoint, the build quality remains class-leading, and the maintenance schedule is remarkably straightforward for a modern adventure motorcycle.
Frequently Asked Questions
Q: Can I use 10W-50 oil?
A: While 10W-40 is the factory standard, 10W-50 may be used in extremely hot climates, provided it meets JASO MA2 specifications.
Q: Is the quickshifter bi-directional?
A: The XTZ700EXP factory quickshifter is designed primarily for upshifts; downshifting still requires manual clutch intervention for smoothness.
